Flutter & Dio: Uploading Files with Progress Indicators

File uploading is a common requirement in many mobile applications, from profile picture updates to document sharing. A crucial aspect of a good user experience during file uploads is providing real-time feedback through a progress indicator. This article will guide you through implementing file uploads in Flutter using the powerful Dio HTTP client, complete with a progress indicator.

Dio is a popular and robust HTTP client for Dart and Flutter. It supports interceptors, global configuration, FormData, request cancellation, file uploading, and downloading with progress, making it an excellent choice for network operations.

Prerequisites

• Basic understanding of Flutter and Dart.
• Flutter SDK installed and configured.
• A running backend server that can handle multipart/form-data file uploads.

1. Setting Up Dio and File Picker

First, add the dio and file_picker (or image_picker if you only need images) packages to your pubspec.yaml file:

dependencies:
  flutter:
    sdk: flutter
  dio: ^5.0.0 # Use the latest version
  file_picker: ^6.0.0 # Use the latest version

Run flutter pub get to install the packages.

2. Understanding File Uploads with Dio

Dio handles file uploads using FormData and MultipartFile.

• MultipartFile.fromFile(): This creates a multipart file from a file path. It automatically infers the content type and filename.
• FormData.fromMap(): This constructs the request body for multipart/form-data. You can add regular fields (like strings) and MultipartFile objects to it.
• onSendProgress Callback: Dio's request methods (like post, put) provide an onSendProgress callback. This callback takes two integer arguments: sent (bytes sent so far) and total (total bytes to send). This is what we'll use to update our progress indicator.

3. Implementing the File Upload Service

Let's create a simple Flutter screen that allows users to pick a file and upload it, showing the progress.

Initialize Dio, for example, globally or within your stateful widget:

final Dio _dio = Dio();

4. Building the UI and Upload Logic

Below is a complete example of a Flutter StatefulWidget that handles file selection, displays upload progress, and triggers the upload.

import 'dart:io';
import 'package:flutter/material.dart';
import 'package:dio/dio.dart';
import 'package:file_picker/file_picker.dart';

class FileUploadScreen extends StatefulWidget {
  @override
  _FileUploadScreenState createState() => _FileUploadScreenState();
}

class _FileUploadScreenState extends State<FileUploadScreen> {
  File? _selectedFile;
  double _progress = 0.0;
  final Dio _dio = Dio(); // Initialize Dio instance

  // Replace with your actual server upload URL
  final String _uploadUrl = "YOUR_SERVER_UPLOAD_URL";

  Future<void> _pickFile() async {
    FilePickerResult? result = await FilePicker.platform.pickFiles();

    if (result != null) {
      setState(() {
        _selectedFile = File(result.files.single.path!);
        _progress = 0.0; // Reset progress when a new file is picked
      });
    } else {
      // User canceled the picker
      print("User canceled the file picker");
    }
  }

  Future<void> _uploadFile() async {
    if (_selectedFile == null) {
      _showMessage("Please select a file first.");
      return;
    }

    String fileName = _selectedFile!.path.split('/').last;
    FormData formData = FormData.fromMap({
      "file": await MultipartFile.fromFile(
        _selectedFile!.path,
        filename: fileName,
      ),
      "folder": "flutter_uploads", // Example of an additional field
    });

    try {
      Response response = await _dio.post(
        _uploadUrl,
        data: formData,
        onSendProgress: (int sent, int total) {
          setState(() {
            _progress = sent / total;
          });
          print("Upload progress: ${(_progress * 100).toStringAsFixed(0)}%");
        },
      );

      _showMessage("File uploaded successfully: ${response.data}");
      print("Server response: ${response.data}");

      // Reset after successful upload
      setState(() {
        _selectedFile = null;
        _progress = 0.0;
      });

    } on DioException catch (e) {
      String errorMessage = "Error uploading file: ${e.message}";
      if (e.response != null) {
        errorMessage += "\nServer response: ${e.response!.data}";
      }
      _showMessage(errorMessage);
      print(errorMessage);
    } catch (e) {
      _showMessage("An unexpected error occurred: $e");
      print("An unexpected error occurred: $e");
    }
  }

  void _showMessage(String message) {
    ScaffoldMessenger.of(context).showSnackBar(
      SnackBar(content: Text(message)),
    );
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text("File Upload with Progress"),
      ),
      body: Padding(
        padding: const EdgeInsets.all(16.0),
        child: Column(
          mainAxisAlignment: MainAxisAlignment.center,
          children: [
            _selectedFile == null
                ? Text("No file selected", style: TextStyle(fontSize: 16))
                : Text(
                    "Selected file: ${_selectedFile!.path.split('/').last}",
                    style: TextStyle(fontSize: 16),
                    textAlign: TextAlign.center,
                  ),
            SizedBox(height: 30),
            ElevatedButton.icon(
              onPressed: _pickFile,
              icon: Icon(Icons.folder_open),
              label: Text("Pick File"),
            ),
            SizedBox(height: 30),
            LinearProgressIndicator(
              value: _progress,
              backgroundColor: Colors.grey[300],
              valueColor: AlwaysStoppedAnimation<Color>(Colors.blue),
            ),
            SizedBox(height: 10),
            Text(
              "Upload Progress: ${(_progress * 100).toStringAsFixed(0)}%",
              style: TextStyle(fontSize: 16),
            ),
            SizedBox(height: 30),
            ElevatedButton.icon(
              onPressed: _selectedFile != null && _progress == 0.0
                  ? _uploadFile
                  : null, // Disable button while uploading or if no file
              icon: Icon(Icons.cloud_upload),
              label: Text("Upload File"),
              style: ElevatedButton.styleFrom(
                padding: EdgeInsets.symmetric(horizontal: 40, vertical: 15),
              ),
            ),
          ],
        ),
      ),
    );
  }
}

Explanation of the Code:

• _selectedFile: A File object to store the file picked by the user.
• _progress: A double value (from 0.0 to 1.0) to represent the upload progress.
• _dio: An instance of the Dio client.
• _pickFile(): Uses FilePicker.platform.pickFiles() to let the user select a file. Once a file is selected, _selectedFile is updated, and _progress is reset.
• _uploadFile():
  • Checks if a file has been selected.
  • Creates a FormData object. It uses MultipartFile.fromFile() to add the selected file and can include other form fields (e.g., "folder": "flutter_uploads").
  • Calls _dio.post() with the _uploadUrl and formData.
  • The onSendProgress callback is crucial. It updates the _progress variable using setState(), which rebuilds the UI and updates the LinearProgressIndicator and the progress text.
  • Error handling for DioException (Dio's specific error type) and general exceptions is included for robustness.
  • After a successful upload, the selected file and progress are reset.
• UI Elements:
  • Text widgets show whether a file is selected and the current progress percentage.
  • ElevatedButton for "Pick File" and "Upload File" actions. The "Upload File" button is disabled if no file is selected or if an upload is already in progress.
  • LinearProgressIndicator visually displays the upload progress based on the _progress value.

5. Server-Side Considerations

The backend server must be configured to accept multipart/form-data requests. For example:

• Node.js (Express with Multer):


  const express = require('express');
  const multer = require('multer');
  const app = express();
  const upload = multer({ dest: 'uploads/' });

  app.post('/upload', upload.single('file'), (req, res) => {
    if (!req.file) {
      return res.status(400).send('No file uploaded.');
    }
    console.log('File uploaded:', req.file);
    console.log('Folder field:', req.body.folder); // Access other fields
    res.send('File uploaded successfully!');
  });

  app.listen(3000, () => console.log('Server started on port 3000'));


• Python (Flask with Werkzeug):


  from flask import Flask, request
  from werkzeug.utils import secure_filename
  import os

  app = Flask(__name__)
  UPLOAD_FOLDER = 'uploads'
  app.config['UPLOAD_FOLDER'] = UPLOAD_FOLDER

  if not os.path.exists(UPLOAD_FOLDER):
      os.makedirs(UPLOAD_FOLDER)

  @app.route('/upload', methods=['POST'])
  def upload_file():
      if 'file' not in request.files:
          return 'No file part', 400
      file = request.files['file']
      if file.filename == '':
          return 'No selected file', 400
      if file:
          filename = secure_filename(file.filename)
          file.save(os.path.join(app.config['UPLOAD_FOLDER'], filename))
          folder_field = request.form.get('folder') # Access other fields
          print(f"File uploaded: {filename}")
          print(f"Folder field: {folder_field}")
          return 'File uploaded successfully', 200
      return 'Something went wrong', 500

  if __name__ == '__main__':
      app.run(debug=True, port=3000)


Remember to replace "YOUR_SERVER_UPLOAD_URL" in the Flutter code with the actual URL of your backend's upload endpoint (e.g., http://localhost:3000/upload if running locally).

Conclusion

By leveraging Dio's FormData and the onSendProgress callback, implementing robust file uploads with clear progress indicators in Flutter is straightforward. This approach greatly enhances the user experience by providing immediate visual feedback, making your applications feel more responsive and professional. Always ensure proper error handling and communicate relevant messages to the user for a smooth interaction.
