Creating a Multi-Level Step Indicator Widget in Flutter

Step indicators are crucial UI components for guiding users through multi-stage processes, such as checkout flows, onboarding tutorials, or multi-part forms. While linear step indicators are common, many real-world processes involve sub-steps or hierarchical structures. A multi-level step indicator provides a more intuitive way to visualize and navigate these complex workflows within a Flutter application.

Understanding the Concept

A multi-level step indicator extends the traditional linear model by allowing steps to have children, creating a tree-like structure. This approach helps users understand the overall progress, while also seeing the granular tasks involved in each major step. Key characteristics include:

• Hierarchy: Steps can be nested, with parent steps containing one or more child steps.
• Visual Indication: Different levels are visually distinguished, often through indentation or varying line styles.
• State Management: Each step (and its children) can have a status (e.g., pending, active, completed).
• Navigation: The ability to move between steps, automatically updating the state of parent and child steps.

Designing the Data Model

The foundation of a multi-level step indicator is a robust data model that can represent the hierarchical nature of the steps. We'll define a simple StepItem class that can recursively hold its children.

import 'package:flutter/material.dart';

enum StepStatus {
  pending,
  active,
  completed,
}

class StepItem {
  final String title;
  final String? subtitle;
  final List<StepItem> children;
  StepStatus status; // Can be managed externally or internally

  StepItem({
    required this.title,
    this.subtitle,
    this.children = const [],
    this.status = StepStatus.pending,
  });

  // Helper to determine if a step (and its children) are completed
  bool get isCompleted => status == StepStatus.completed;

  // Helper to determine if a step (or any of its children) are active
  bool get isActive => status == StepStatus.active;
}

Building the Recursive Step Tile Widget

To render each step and its children, we'll create a reusable widget, let's call it _StepTile. This widget will be responsible for drawing a single step's indicator, title, and then recursively rendering its children with appropriate indentation and connecting lines.

class _StepTile extends StatelessWidget {
  final StepItem step;
  final int level;
  final bool isLastChild;
  final bool hasNextSibling;
  final ValueChanged<StepItem> onStepTapped;

  const _StepTile({
    required this.step,
    this.level = 0,
    this.isLastChild = false,
    this.hasNextSibling = false,
    required this.onStepTapped,
  });

  Widget _buildIndicator() {
    IconData icon;
    Color color;

    switch (step.status) {
      case StepStatus.completed:
        icon = Icons.check_circle;
        color = Colors.green;
        break;
      case StepStatus.active:
        icon = Icons.radio_button_checked;
        color = Colors.blue;
        break;
      case StepStatus.pending:
        icon = Icons.radio_button_unchecked;
        color = Colors.grey;
        break;
    }

    return Icon(icon, color: color, size: 24);
  }

  @override
  Widget build(BuildContext context) {
    return Column(
      crossAxisAlignment: CrossAxisAlignment.start,
      children: [
        GestureDetector(
          onTap: () => onStepTapped(step),
          child: Padding(
            padding: EdgeInsets.only(left: level * 20.0), // Indentation
            child: Row(
              crossAxisAlignment: CrossAxisAlignment.center,
              children: [
                _buildIndicator(),
                const SizedBox(width: 8),
                Expanded(
                  child: Column(
                    crossAxisAlignment: CrossAxisAlignment.start,
                    children: [
                      Text(
                        step.title,
                        style: TextStyle(
                          fontWeight: step.isActive ? FontWeight.bold : FontWeight.normal,
                          color: step.isActive ? Colors.blue : Colors.black87,
                        ),
                      ),
                      if (step.subtitle != null)
                        Text(
                          step.subtitle!,
                          style: TextStyle(
                            fontSize: 12,
                            color: Colors.grey[600],
                          ),
                        ),
                    ],
                  ),
                ),
              ],
            ),
          ),
        ),
        if (step.children.isNotEmpty)
          Padding(
            padding: EdgeInsets.only(left: (level * 20.0) + 12), // Align vertical line
            child: Stack(
              children: [
                // Vertical line connecting to children
                Positioned(
                  left: 0,
                  top: 0,
                  bottom: 0,
                  child: Container(
                    width: 2,
                    color: Colors.grey[300],
                  ),
                ),
                Column(
                  crossAxisAlignment: CrossAxisAlignment.start,
                  children: List.generate(step.children.length, (index) {
                    final childStep = step.children[index];
                    return _StepTile(
                      step: childStep,
                      level: level + 1,
                      isLastChild: index == step.children.length - 1,
                      hasNextSibling: index < step.children.length - 1,
                      onStepTapped: onStepTapped,
                    );
                  }),
                ),
              ],
            ),
          ),
        // Spacer between main steps, or if it's not the very last item in a parent's children
        if (!isLastChild && level == 0) // Only add divider for top-level steps
          const Padding(
            padding: EdgeInsets.symmetric(vertical: 8.0, horizontal: 16.0),
            child: Divider(height: 1, thickness: 1),
          )
        else if (hasNextSibling && level > 0) // Add vertical line segment between children of the same parent
          Padding(
            padding: EdgeInsets.only(left: (level * 20.0) + 12, bottom: 8),
            child: Container(
              height: 12, // Small vertical line segment
              width: 2,
              color: Colors.grey[300],
            ),
          ),
      ],
    );
  }
}

The Main Multi-Level Step Indicator Widget

This widget will hold the list of StepItems and manage their state. It will iterate through the top-level steps and use our _StepTile to render them recursively. It will also provide methods to navigate or update step statuses.

class MultiLevelStepIndicator extends StatefulWidget {
  final List<StepItem> steps;
  final int initialActiveStepIndex; // For top-level steps
  final ValueChanged<StepItem>? onStepTapped;

  const MultiLevelStepIndicator({
    super.key,
    required this.steps,
    this.initialActiveStepIndex = 0,
    this.onStepTapped,
  });

  @override
  State<MultiLevelStepIndicator> createState() => _MultiLevelStepIndicatorState();
}

class _MultiLevelStepIndicatorState extends State<MultiLevelStepIndicator> {
  late List<StepItem> _currentSteps;

  @override
  void initState() {
    super.initState();
    _currentSteps = _initializeSteps(widget.steps, widget.initialActiveStepIndex);
  }

  // Deep copy and initial status setup
  List<StepItem> _initializeSteps(List<StepItem> originalSteps, int initialIndex) {
    List<StepItem> newSteps = [];
    for (int i = 0; i < originalSteps.length; i++) {
      StepItem original = originalSteps[i];
      StepStatus status = StepStatus.pending;
      if (i < initialIndex) {
        status = StepStatus.completed;
      } else if (i == initialIndex) {
        status = StepStatus.active;
      }

      newSteps.add(StepItem(
        title: original.title,
        subtitle: original.subtitle,
        children: _initializeChildSteps(original.children, status == StepStatus.active),
        status: status,
      ));
    }
    return newSteps;
  }

  List<StepItem> _initializeChildSteps(List<StepItem> originalChildren, bool parentIsActive) {
    if (!parentIsActive) return originalChildren.map((e) => StepItem(title: e.title, subtitle: e.subtitle, children: e.children, status: StepStatus.pending)).toList();

    // If parent is active, make the first child active by default, or all children pending.
    List<StepItem> newChildren = [];
    for (int i = 0; i < originalChildren.length; i++) {
      StepItem original = originalChildren[i];
      StepStatus status = StepStatus.pending;
      if (i == 0) { // First child is active if parent is active
         status = StepStatus.active;
      }
      newChildren.add(StepItem(
        title: original.title,
        subtitle: original.subtitle,
        children: _initializeChildSteps(original.children, status == StepStatus.active),
        status: status,
      ));
    }
    return newChildren;
  }


  // Method to update the status of steps
  void _updateStepStatus(StepItem tappedStep) {
    setState(() {
      bool foundActive = false;
      for (var topLevelStep in _currentSteps) {
        _recursivelyUpdateStatus(topLevelStep, tappedStep, false, foundActive);
        if (topLevelStep.status == StepStatus.active) {
            foundActive = true;
        }
      }
    });
    widget.onStepTapped?.call(tappedStep);
  }

  void _recursivelyUpdateStatus(StepItem currentStep, StepItem targetStep, bool parentCompleted, bool parentActiveBefore) {
    // If the target step is found, make it active. All steps before it are completed. All steps after are pending.
    if (currentStep == targetStep) {
      currentStep.status = StepStatus.active;
    } else if (parentCompleted || (parentActiveBefore && currentStep.status != StepStatus.active && currentStep.status != StepStatus.completed)) {
      currentStep.status = StepStatus.pending; // Reset steps after active
    } else if (currentStep.status == StepStatus.active) {
       currentStep.status = StepStatus.completed; // If current was active, it's now completed
    } else if (currentStep.status != StepStatus.completed) {
       currentStep.status = StepStatus.pending;
    }

    bool currentCompleted = currentStep.status == StepStatus.completed;
    bool currentActive = currentStep.status == StepStatus.active;

    for (var child in currentStep.children) {
      _recursivelyUpdateStatus(child, targetStep, currentCompleted, currentActive);
    }

    // After updating children, if all children are completed, parent can be completed too
    if (currentStep.children.isNotEmpty && currentStep.children.every((child) => child.isCompleted)) {
      currentStep.status = StepStatus.completed;
    }
  }


  @override
  Widget build(BuildContext context) {
    return Column(
      crossAxisAlignment: CrossAxisAlignment.start,
      children: List.generate(_currentSteps.length, (index) {
        final step = _currentSteps[index];
        return _StepTile(
          step: step,
          level: 0,
          isLastChild: index == _currentSteps.length - 1,
          hasNextSibling: index < _currentSteps.length - 1,
          onStepTapped: _updateStepStatus,
        );
      }),
    );
  }
}

Example Usage

Here's how you might integrate the MultiLevelStepIndicator into a Flutter application:

class MyApp extends StatelessWidget {
  const MyApp({super.key});

  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: 'Multi-Level Step Indicator Demo',
      theme: ThemeData(
        primarySwatch: Colors.blue,
      ),
      home: const MyHomePage(),
    );
  }
}

class MyHomePage extends StatefulWidget {
  const MyHomePage({super.key});

  @override
  State<MyHomePage> createState() => _MyHomePageState();
}

class _MyHomePageState extends State<MyHomePage> {
  final List<StepItem> _steps = [
    StepItem(
      title: 'Personal Information',
      subtitle: 'Provide your name and contact details.',
      children: [
        StepItem(title: 'Basic Details', subtitle: 'Name, Email'),
        StepItem(title: 'Address', subtitle: 'Street, City, Postal Code'),
        StepItem(title: 'Contact Preferences'),
      ],
    ),
    StepItem(
      title: 'Account Setup',
      subtitle: 'Create your username and password.',
      children: [
        StepItem(title: 'Choose Username'),
        StepItem(title: 'Set Password', children: [
          StepItem(title: 'Minimum 8 characters'),
          StepItem(title: 'Include special character'),
        ]),
        StepItem(title: 'Security Questions'),
      ],
    ),
    StepItem(
      title: 'Payment Details',
      subtitle: 'Select payment method.',
    ),
    StepItem(
      title: 'Review & Confirm',
      subtitle: 'Final check before submission.',
    ),
  ];

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: const Text('Multi-Level Steps'),
      ),
      body: SingleChildScrollView(
        padding: const EdgeInsets.all(16.0),
        child: MultiLevelStepIndicator(
          steps: _steps,
          initialActiveStepIndex: 0,
          onStepTapped: (step) {
            print('Tapped: ${step.title}');
            // You can add logic here to navigate to a specific form section
          },
        ),
      ),
    );
  }
}

Conclusion

Creating a multi-level step indicator in Flutter involves a recursive approach to both data modeling and UI rendering. By defining a hierarchical StepItem and a recursive _StepTile widget, we can effectively visualize complex workflows. The main MultiLevelStepIndicator widget then manages the overall state and user interactions, providing a robust and flexible solution for guiding users through nested processes. This implementation offers a solid foundation that can be further enhanced with custom animations, different visual styles, and more sophisticated state management solutions like Provider or BLoC for larger applications.
